96fo High Density MPO Fiber Optic Patch Panel 1U 19'' MTP Rack Mount Fiber Optic Termination Box

Brand Name : KCO

Model Number : MPO-1U-96-LC/UPC

Certification : RoHS, ISO9001

Place of Origin : Guangdong, China

MOQ : Negotiation

Price : Negotiation

Payment Terms : Western Union,T/T,L/C

Supply Ability : 50,000pcs/month

Delivery Time : 2~7 days after get payment

Packaging Details : PE bag, carton box, wooden pallet

Connector 1 : MPO, MTP

Connector 2 : LC/UPC, LC/APC or customized

Size : 480x245x1U

Capacity : 96 cores

Color : black, beige

Length : 0.5m, 1.0m, 1.5m, customized

Contact Now

96core LC/UPC SM High Density MPO Patch Panel 1U 19'' Rack Mount Fiber Optic Termination Box

Our advantages:

Kocent Optec Limited is one of lead passive fiber optic product supplier in China.
Kocent Optec Limited with more than 10 years of experiences in fiber optic industry, we provide OEM and ODM service for all type of MPO/MTP rack mountable patch panel.
With full set of production line for steel tape production (to make all type of ODF) and production line for MPO patch cord, we supply the MPO/MTP patch panel with full loaded of patch cable and adapter.
All installation charge is free.

Quick informations:

Connector 1: MPO, MTP fanout patch cable
Connector 2: LC/UPC, LC/APC, LC MM
Modular number: 4pcs
Cable length: 0.3m
Patch panel size: 480x245x1U(mm)
Capacity: 96 cores

Features:

19" standard size, easy install.
Fit with 19'' Rack type Cabinet.
Light weight, strong strength, good anti-shocking and dustproof
Well cable management, cable can be distinguished easily
Roomy space ensure fiber bent ratio
Provides a complete system solution for connectivity
Provide higher patch field density in fewer rack units saving valuable space
Assures flexibility and ease of network deployment and moves, adds, and changes

Product photo:

96fo High Density MPO Fiber Optic Patch Panel 1U 19'' MTP Rack Mount Fiber Optic Termination Box

MTP/MPO Connector Specifications:

Type	Single Mode		Single Mode		Multi Mode
	(APC Polish)		(UPC Polish)		(PC Polish)
Fiber Count	8,12,24 etc.		8,12,24 etc.		8,12,24 etc.
Fiber Type	G652D,G657A1 etc.		G652D,G657A1 etc.		OM1,OM2,OM3 etc.
Max. Insertion Loss	Elite	Standard	Elite	Standard	Elite	Standard
	Low Loss		Low Loss		Low Loss
	≤0.35 dB	≤0.75dB	≤0.35 dB	≤0.75dB	≤0.35 dB	≤0.60dB
Return Loss	≥60 dB		≥60 dB		NA
Durability	≥500 times		≥500 times		≥500 times
Operating Temperature	-40℃~+80℃		-40℃~+80℃		-40℃~+80℃
Test Wavelength	1310nm		1310nm		1310nm
Insert-pull test	1000 times＜0.5 dB
Interchange	＜0.5 dB
Anti-tensile force	15kgf

Descriptions:

Fiber Capacity of panel	12-144 core(12 24 48 port usually)
Panel Connector	SC LC ST FC
Type	Fixed
Dimension	19'' 1U/2U/3U/4U...
Material	Cold Rolled Steel or Aluminum
Storage Temperature	-45~+65℃
Thickness	1.0 1.2 mm
Accessories	Cable ties, mounting ear screws, and spiral wrap tube
MPO type	SM: G652D, G657A1, G657A2 MM: OM1, OM2, OM3, OM4, OM5
Cover	LSZH
Length	0.3m, 0.5m

OEM/ODM Service:

If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.

96fo High Density MPO Fiber Optic Patch Panel 1U 19'' MTP Rack Mount Fiber Optic Termination Box

Packing:

According to Stardard Export Packing.

Carton box, wooden box, wooden pallet.

Shipping:

International express such as UPS, TNT, DHL, etc
Internatioal air: CA, AA, EA, etc
By sea
